Pentair La Sta-rite 5P2R Pool Pump
The current version of the classic Sta-Rite 5P2R, built by Pentair in Italy. A tough single speed pump with high head impellers, a big strainer basket and 1.5" BSP ports, from 0.5HP to 1.5HP.
Replacing an old 5P2R and need a hand? We work with over 1,000 trade installers across the UK and can arrange for one to fit it for you. Just get in touch.
Found it cheaper elsewhere? Fill in our price match form and we'll do our best to match or beat it.
The current version of the classic Sta-Rite 5P2R, built by Pentair in Italy. A tough single speed pump with high head impellers, a big strainer basket and 1.5" BSP ports, from 0.5HP to 1.5HP.
Replacing an old 5P2R and need a hand? We work with over 1,000 trade installers across the UK and can arrange for one to fit it for you. Just get in touch.
Found it cheaper elsewhere? Fill in our price match form and we'll do our best to match or beat it.
About the Pentair La Sta-Rite (5P2R) Pool Pump
If you've had a pool in the UK for any length of time, there's a fair chance a Sta-Rite 5P2R has been sat in your plant room at some point. It's been the go-to pump for domestic pools for decades, and the current Pentair La Sta-Rite is the version of that pump being built today, at Pentair's own factory in Pisa, Italy.
It's a simple, tough single speed pump. The glass-reinforced body handles pressure well, the stainless steel locking clamp means you can get into the wet end in minutes, and the extra-large strainer basket lets you go longer between emptying it. The high head impellers are a real help where the plant room is a long way from the pool and the pipe runs are long.
You can choose from 0.5HP up to 1.5HP, in single phase (230V) or three phase (400V). Both ports are 1.5" BSP and 50mm unions come in the box. It's also happy on salt chlorinated pools up to 0.4% salt (4 g/l).
Not sure which size you need? Send us your pool volume and the distance to the plant room and our tech team will point you at the right model.
Â
Key features
- Stainless steel locking clamp for quick access to the impeller and seal
- Extra-large strainer basket, so fewer trips to empty it
- High head impellers, good for long pipe runs to the plant room
- Induction motor with SKF sealed bearings and a stainless steel (AISI 304) drive-end shaft
- Thermal protection on single phase models. Three phase motors are IE2 (under 0.75kW) or IE3 (0.75kW and above)
- 1.5" BSP inlet and outlet, 50mm unions included
- Suitable for salt pools up to 0.4% (4 g/l)
Â
Pentair La Sta-Rite (5P2R) Pool Pump specifications
Â
| Part number | Power | Flow at 8m head | Voltage | Phase | P1 (Input kw) | P2 (Output kw) | Length (A) | Weight |
|---|---|---|---|---|---|---|---|---|
| STA-100-0534 | 0.37kW (0.5HP) | 8 m³/h | 220-240V | Single | 0.7kw | 0.37kw | 514 mm | 14.1 kg |
| STA-100-0536 | 0.55kW (0.75HP) | 12 m³/h | 220-240V | Single | 0.9kw | 0.55kw | 514 mm | 14.1 kg |
| STA-100-0537 | 0.55kW (0.75HP) | 12 m³/h | 380-420V | Three |  |  | 514 mm | 14 kg |
| STA-100-0538 | 0.75kW (1HP) | 16 m³/h | 220-240V | Single | 1.1kw | 0.75kw | 514 mm | 15.8 kg |
| STA-100-0539 | 0.75kW (1HP) | 16 m³/h | 380-420V | Three |  |  | 514 mm | 25 kg |
| STA-100-0540 | 1.1kW (1.5HP) | 20 m³/h | 220-240V | Single | 1.3kw | 1.1kw | 544 mm | 17 kg |
| STA-100-0541 | 1.1kW (1.5HP) | 20 m³/h | 380-420V | Three |  |  | 544 mm | 26 kg |
| Specification | Detail |
|---|---|
| Inlet / outlet | 1.5" BSP |
| Unions | 50mm internal, included |
| Width | 288 mm |
| Height | 366 mm |
| Motor protection | IPX5 |
| Bearings | SKF sealed |
| Shaft | Bi-material, stainless steel AISI 304 drive end |
| Salt tolerance | Up to 0.4% (4 g/l) |
| Maximum height above water level | 2.5 m |
| Boxed size | 64 x 32 x 36 cm |
| Made in | Pisa, Italy |
Replacing an older Sta-Rite 5P2R?
Match on motor power. Older 5P2R models were coded by letter, with -1 for single phase and -3 for three phase.
Â
| Old 5P2R model | Motor | Current La Sta-Rite |
|---|---|---|
| 5P2RC-1 / 5P2RC-3 | 0.37kW (0.5HP) | STA-100-0534 |
| 5P2RD-1 / 5P2RD-3 | 0.55kW (0.75HP) | STA-100-0536 / STA-100-0537 |
| 5P2RE-1 / 5P2RE-3 | 0.75kW (1HP) | STA-100-0538 / STA-100-0539 |
| 5P2RF-1 / 5P2RF-3 | 1.1kW (1.5HP) | STA-100-0540 / STA-100-0541 |
Â
Warranty
Pentair cover the La Sta-Rite with a limited 3 year manufacturer's warranty. As with any pool pump, it needs to be installed by a qualified person and wired by an electrician, and damage caused by running the pump dry or by frost isn't covered. If something does go wrong, call us first and we'll help you sort it out with Pentair.
2 Year Warranty on motor and motor components*
90 days on mechanical seal & bearingsÂ
Domestic Pumps not warranted to run 24 hours a day.
Â
Frequently asked questions
Is the Pentair La Sta-Rite the same as the Sta-Rite 5P2R?
It's the current version of the same pump. Pentair now own Sta-Rite, and the La Sta-Rite is what replaced the 5P2R. Power ratings match and the ports are still 1.5" BSP, so in most plant rooms it's a straightforward swap. Use the table above to find the model that matches your old one.
Â
What size La Sta-Rite do I need for my pool?
As a rough guide, you want to turn over the whole pool volume in about 6 to 8 hours. A 50 m³ pool needs roughly 7 to 8 m³/h, so the 0.5HP or 0.75HP would usually cover it. Pipe length, filter size and any extras like solar panels or a heat pump all add resistance, so give our tech team a call if you're between sizes.
Â
Can I use the La Sta-Rite on a salt water pool?
Yes. Pentair rate it for salt levels up to 0.4% (4 g/l), which covers most salt chlorinator setups. The motor shaft has a stainless drive end and the body is corrosion resistant.
Â
Can the pump sit above the pool water level?
Yes, it's self-priming and will lift water up to 2.5 m. Fill the strainer pot with water before the first start and check the lid O-ring is clean and lubricated, otherwise it'll struggle to prime.
Â
Do I need a single phase or three phase pump?
Almost every UK home has a single phase 230V supply, so the single phase models (part numbers ending in 1) are the ones most people need. Three phase is mainly for commercial sites and larger properties with a 400V supply. If you're not sure, your electrician can tell you in a minute.
