Elecro Optima Compact Electric Pool Heater

Elecro Optima Compact

The Optima Compact delivers everything you need in a pool heater - safety, reliability, efficiency and touchscreen digital programming for any modern lifestyle. A highly robust, durable construction, makes this a desirable solution for any residential pool or spa.



Features & Benefits

---

• 23 models available, ranging from 1-kW to 24-kW
• Easy installation, fully equipped and pre-wired
• Robust, durable construction
• Ultra-reliable flow switch allows safe operation
• Fitted with temperature thermostat and overheating sensor
• Compact, durable design
• Touchscreen control with soft-start for power supply protection
• Titanium flow tube and titanium heating element(s)
• Can be floor or vertically wall mounted
• Vortex, long life, stay clean heating element technology
• 100% efficiency throughout the product life
• Silent operation



Simplify your life with the Elecro ‘TouchSmart’ app

---

Connection via Wi-Fi, 4G and Cloud enables you to take full control of your swimming pool heating from anywhere in your home or office, with a simple app on your smartphone

Please note - all Elecro Optima Compacts are 'special' order items which would be dispatched directly from the supplier.





Optima Compact (Residential Pool Heater) - Installation and Maintenance

---



Models

---



Model	Model Code	Power Output	Load (amp)	Net Weight (kg)	Gross Weight (kg)	Volume (m3)
220-240V 1-Phase	OCPD-1-2	2kW	8.5	7.19	8.83	0.057
	OCPD-1-3	3kW	12	7.19	8.83	0.057
	OCPD-1-4	4.5kW	20	7.19	8.83	0.057
	OCPD-1-6	6kW	26	7.19	8.83	0.057
	OCPD-1-9	9kW	40	7.51	9.15	0.057
	OCPD-1-12	12kW	53	7.51	9.15	0.057
	OCPD-1-15	15kW	66	7.84	9.48	0.057
	OCPD-1-18	18kW	79	7.84	9.48	0.057
230/400V Versatile*	OCPD-V-9	9-kW	40/13	7.72	9.36	0.057
	OCPD-V-12	12-kW	55/18	7.72	9.36	0.057
400V 3-Phase	OCPD-3-15	15-kW	22	7.72	9.36	0.0571
	OCPD-3-18	18-kW	26	7.72	9.36	0.0571
	OCPD-3-24	24-kW	34	7.72	9.36	0.0571



Pressure Drop

---



Schematics

---



Specifications

---

Power Supply	Single phase or three phase
Flow Requirements	Minimum flow: 2-kW to 6-kW, 1m3/h Minimum flow: 9-kW to 24-kW, 4m3/h Maximum flow: 17m3/h
Heating Element	Grade 1 titanium
Flow Tube	Grade 1 titanium
Control Thermostat	Touch Screen 0 > 45 C (0.5 C differential)
Safety Thermal Cut Out	60°C (manual reset)
Flow Switch	Rhodium tipped reed switch with titanium fulcrum pin
Contractors	Dual Siemens 3RT2023 or 3RT2027
Seals	High temperature special formula EPDM ferrules, TPE end fitting gaskets
Water Connections	1.5” BSP female thread supplied with 1½” / 50mm stepped PVC unions for rigid pipe and 1½” / 1¼” stepped hose tails for flexible pipe
International Protection Marking	IP44
Frequency	50/60 Hz
Working Pressure	4 bar maximum
Mounting	Floor or wall mounting



Dimensions

---
